Product  LUS211-130-51-2UPN8-H1141

Ultrasonic Sensor

Level Control

Ident. no.: 100003165
    • 4-digit, 2-colored, 12-segment display, rotatable by 180°
    • Housing is rotatable after mounting the process connection
    • G3/4" process connection
    • Sealing ring included in delivery (stainless steel ring with NBR seal)
    • Blind zone: 13 cm
    • Range: 130 cm
    • Resolution: 1 mm
    • Aperture angle of sonic cone: ±16 °
    • 2 × switching outputs, PNP/NPN
    • NO/NC programmable
    • Transmission of process value and parametrization via IO-Link

General data

EAN 4047101476217
eCl@ss-Code (V5.1.4): 27272803 -/- Ultrasonic proximity switch
Customs tariff number 85365019900
Country of origin DE
Weight 427 g

Technical Data

Detection type contactless
Medium liquids, Bulk goods
Measuring principle Ultrasonic
Process connection G 3/4''
Max. range 1300  mm
Operating voltage 18…33 VDC
Output function NO/NC, PNP
Communication protocol IO-Link
Electrical connection Connector, M12 × 1
Housing material Stainless-steel/Plastic, 1.4404 (AISI 316L)/Grilamid TR90 UV PA
Pressure resistance 0.5…5 bar
Ambient temperature -25…+70 °C
Protection class IP67/IP69K
Approvals CE, cULus
