Product  BI4-M12E-AP6X-H1141

Inductive Sensor

With Increased Switching Distance

Ident. no.: 4608030
    • M12 × 1 threaded barrel
    • Long version
    • Chrome-plated brass
    • Large sensing range
    • DC 3-wire, 10…30 VDC
    • NO contact, PNP output
    • M12 x 1 male connector

General data

EAN 4047101098853
eCl@ss-Code (V5.1.4): 27270101 -/- Inductive proximity switch
Customs tariff number 85365019900
Country of origin DE
Weight 29.483 g

Technical Data

Design Threaded barrel
Construction size M12 x 1
Rated switching distance 4 mm
Mounting Flush
Operating voltage 10…30 VDC
Output function NO contact, PNP
Switching frequency 2.0 kHz
Electrical connection Connector, M12 × 1
Housing material Metal, CuZn, Chrome-plated
Ambient temperature -25…+70 °C
Protection class IP67
Special features Sn +
