Product  BLCDN-4M12S-8DI-PD

BL compact™ fieldbus station for DeviceNet™

8 Digital PNP Inputs

Ident. no.: 6811005
    • On-machine Compact fieldbus I/O block
    • DeviceNet™ slave
    • 125 / 250 / 500 kbps
    • Two 5-pole M12 connectors for fieldbus connection
    • 2 rotary switches for node address
    • IP67, IP69K
    • M12 I/O connectors
    • LEDs indicating status and diagnostics
    • Electronics galvanically separated from the field level via optocouplers
    • 8 digital PNP inputs, 24 VDC
    • Channel diagnostics
    • Wire-break monitoring
    • Selection of filtering times (Input delay)
    • Invertible inputs
#

General data

EAN 4047101198232
eCl@ss-Code (V5.1.4): 27250313 -/- Communication interface, passive
Customs tariff number 8536908530
Country of origin US
Weight 380 g

Technical Data

Fieldbus Protocol DeviceNet
Signal type Digital input
Connection technology signal M12
Device type I/O Module, Compact station
Fieldbus transmission rate 125/250/500 kbps
Fieldbus connection technology 2 × M12
Ambient temperature -40…+70 °C
Protection class IP67/IP69K

Connectivity accessories — I/O

U2151-3
U2445
U2187-1

Connectivity accessories — Network

U0323
