Product BL67-2RFID-A
BL67 Electronic Module
2 RFID Channels (HF/UHF)
Ident. no.: 6827225- This module is used with the BL67‐GW‐DPV1
- Protection class IP67
- LEDs indicate status and diagnostic
- Electronics galvanically separated from the field level via optocouplers
- Connection of two BL ident read/write heads
- Mixed operation of HF and UHF read/write heads
- Transmission rate: 115.2 kbps
- Cable length max. 50 m
General data
| EAN | 4047101109443 |
| eCl@ss-Code (V5.1.4): | 27280401 -/- Identification RFID |
| Customs tariff number | 85389091890 |
| Country of origin | DE |
| Weight | 57 g |
Technical Data
| Number of channels | 2 |
| Ambient temperature | -40…+70 °C |
| Protection class | IP67 |
