Product BL67-4AI-TC
BL67 electronic module
4 Analog Inputs for Thermoelements
Ident. no.: 6827368- Independent of the fieldbus and connection technology used
- Protection class IP67
- LEDs indicate status and diagnostic
- Electronics galvanically separated from the field level via optocouplers
- 4 analog inputs for the connection of thermocouples
- Types B, C, E, G, J, K, N, R, S and T
- Cold junction compensation via Pt1000 probe in a special connector
General data
| EAN | 4047101252910 |
| eCl@ss-Code (V5.1.4): | 27250303 -/- Analog I/O module |
| Customs tariff number | 85389091890 |
| Country of origin | DE |
| Weight | 52 g |
Technical Data
| Signal type | Analog input, Temperature |
| Connection technology signal | M12 |
| Device type | I/O Module |
| Ambient temperature | -40…+70 °C |
| Protection class | IP67 |
| Approvals | cULus |
