Product  LT14E-Q21-LU0X3-H1141

Magnetically actuated linear position sensor

Ident. no.: LT0307
    • EZ-Track Linear Displacement Transducer
#

Technical Data

Design Profile
Measuring principle Magnetostrictive
Measuring range 355.6 mm [14.00 in]
Output function Analog output
Voltage output 0…10 V
Electrical connection Connector, M12 × 1
Housing material Metal, AL
Ambient temperature -40…+70 °C
Protection class IP67
Approvals FM C1D2, CE

Data Sheets

CAD File

Catalog

Product Datasheet
