Product LTX5.5E-R10-LU0X3H1151
Magnetically actuated linear position sensor
Ident. no.: LT0832- EZ-Track Linear Displacement Transducer
Technical Data
| Design | Rod |
| Measuring principle | Magnetostrictive |
| Measuring range | 139.7 mm [5.50 in] |
| Output function | Analog output |
| Voltage output | 0…10 V |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Metal, AL |
| Ambient temperature | -40…+85 °C |
| Protection class | IP68 |
| Approvals | CE |
