Product  PS510-100-03-LI2UPN8-H1141

Pressure Sensor

Relative Pressure: 0…100  Bar

Ident. no.: 100001571
    • 4-digit, 2-color (red/green), 12-segment display, rotatable by 180°
    • Housing is rotatable after mounting the process connection
    • Metal measuring cell
    • Pressure range 0…100 bar relative
    • 18…33 VDC
    • NO/NC contact, PNP/NPN output, analog output (current/voltage), IO-Link SSP4.1.1
    • Process connection 1/4″ NPT male thread
    • Connector device, M12 × 1
#
Hide All Open All

General data

EAN 4047101555349
eCl@ss-Code (V5.1.4): 27200614 -/- Piezoresistive sensor (absolute and relative pressure)
Customs tariff number 8538908180
Country of origin DE
Weight 278 g

Technical Data

Design With display
Process connection 1/4″ NPT-18 male thread
Pressure type Relative pressure
Pressure range bar 0…100 bar
Pressure range psi 0…1450.38 psi
Operating voltage 18…33 VDC
Electrical output Switching output, Current output (3-wire), Voltage output (3-wire), IO-Link
Voltage output 0…10 V
Current output 4…20 mA
Communication protocol IO-Link
Electrical connection Connector, M12 × 1
Housing material Stainless-steel/Plastic, 1.4404 (AISI 316L)/Grilamid TR90 UV/Elastollan C 65 A 15 HPM 000/Ultramid A3X2G5
Materials (contact with media) Stainless steel 1.4404 (AISI 316L)/1.4542 (AISI 630)
Medium temperature -40…+80 °C
Ambient temperature -40…+80 °C
Protection class IP66/IP67/IP69K
Approvals CE, Metrological certification (RUS), cULus

Mounting accessories

FAM-30-PA66

Mounting bracket; variable wrench size 24–30 mm; removable labeling plate 20 × 9 mm

 100018384

Functional accessories

USB-2-IOL-0002

IO-Link Master with integrated USB port

 6825482
