Product MBD40-4R/EX
Multibarrier, 4-Channel
FOUNDATION Fieldbus and PROFIBUS-PA
Ident. no.: 6611701- Galvanically separated Ex e bus cables and Ex i outputs
- Temperature range: ‐40…+75 °C(‐40…+167 °F)
- Integrated terminating resistor (optional activation)
- output data: 10V/40mA (short-circuit proof)
- Entity and FISCO compliant acc. to 60079‐27
General data
| EAN | 4047101226294 |
| eCl@ss-Code (V5.1.4): | 27250201 -/- Network components (fieldbus) |
| Customs tariff number | 85369095000 |
| Country of origin | DE |
| Weight | 945 g |
Technical Data
| Fieldbus Protocol | FOUNDATION fieldbus, PROFIBUS-PA |
| Device type | Multibarrier |
| Ambient temperature | -40…+75 °C |
| Protection class | IP20 |
| Approvals | ATEX, IECEx, FM |
