Product DPC-49-4RMB
Module Rack for the DPC System
FOUNDATION Fieldbus
Ident. no.: 6882024- Module rack for up to eight power supply modules and one diagnostic module for up to four redundant H1 segments.
- Redundant power supply
- Removable terminal blocks with screw connections
- RJ45 connector for HSE fieldbus diagnostics
General data
| EAN | 4047101207736 |
| eCl@ss-Code (V5.1.4): | 27250301 -/- Module rack (periphery) |
| Customs tariff number | 85381000000 |
| Country of origin | DE |
| Weight | 1548 g |
Technical Data
| Fieldbus Protocol | FOUNDATION fieldbus |
| Connection technology signal | Screw terminal |
| Device type | Module Racks |
| Ambient temperature | -20…+60 °C |
| Protection class | IP20 |
