Product SE20-84XT-RJ422-FO
Industrial Ethernet
Unmanaged Switch
Ident. no.: U3-10873- 10/100 Mbps
- Auto-sensing, 10/100M, half/full duplex, auto-negotiating
- Auto cross-over, auto-polarity
- Automatic address learning, aging and migration
- Store and forward wire-speed switching
- IEEE 802.3, 802.3u, 802.3x
- 4 ports + 1 multi-mode fiber
- Ethernet connection: shielded RJ45 sockets
- Power supply: removable screw terminal
- Protection class: IP20
General data
| EAN | 4047101300482 |
| eCl@ss-Code (V5.1.4): | 19170130 -/- Netzwerk-Switch (allgemeine Anwendung) |
| Customs tariff number | 85176200000 |
| Country of origin | US |
| Weight | 223 g |
Technical Data
| Device type | Ethernet switch |
| Fieldbus connection technology | 4 x RJ45 sockets; 1 x Duplex SC fiber socket |
| Transmission rate Ethernet | 10/100 Mbps |
| Number of Ethernet ports | 4 ports (unmanaged) + 1 multi-mode fiber |
| Connection technology Ethernet | 4 × RJ45, 1 × Duplex SC |
| Ambient temperature | -40…+60 °C |
| Protection class | IP20 |
