Product BS 7181-0/21
Actuator and Sensor Field Wireable
1” Connection
Ident. no.: U2-04066- Screw terminal Wire Termination
- Plastic housing
- 1” Male, Straight, 8-pin
- Plastic Housing
General data
| EAN | 4047101565973 |
| Customs tariff number | 85366990990 |
| Country of origin | MX |
| Weight | 100 g |
Technical Data
| Application | Signal |
| Connector A | Male, 1″-16 UN, Straight |
| Number of contacts | 8 |
| Connection mode | Screw/clamp connection |
| Housing material | Plastic, PBT |
| Coupling nut/screw material | Brass, CuZn, Nickel-plated |
| Acceptable cable diameter | 13…18 mm |
| Voltage | 600 V |
| Current | 8 A |
