Product FKDV FSDV 44/M12
Ethernet Receptacle
Panel Feed-through
Ident. no.: U2-19500- Female M12 eurofast Receptacle
- Male M12 eurofast Receptacle
Technical Data
| Application | Data |
| Design | Double-ended |
| Connector A | Female, M12 × 1, D-code |
| Number of contacts | 4 |
| Housing material/finish | Stainless Steel, Passivated |
| Mounting orientation | Front mount |
| Mounting thread | M12 × 1 |
| Connector B | Male, M12 × 1, D-code |
| Number of contacts | 4 |
| Housing material/finish | Stainless Steel, Passivated |
| Mounting type | Rear mount |
| Mounting Thread B | M12 × 1 |
| Fieldbus Protocol | Ethernet |
| Voltage | 150 V |
| Current | 4 A |
| Approvals | UL Listed, CSA, RoHS |
